Warehouse Layout Design and Flow
Move the machines on paper before you move them on concrete.
A layout mistake costs a few hours to fix in AutoCAD and a few hundred thousand to fix in steel. Conveyability designs facility layouts from the data — cube utilization, movement reports, projected material flow — and the constraints that don’t move: building columns, docks, machine locations. Drawn in modules, so when the plan changes, the drawing changes with it.
Built from movement reports and projected flow, not guesswork.
Columns, docks and existing machines treated as the real drawing.
Modular AutoCAD layouts, so changes stay cheap while they’re still on paper.
Combined team member material handling experience.
Designed in modules so changes land easily.
Movement reports and flow before any equipment list.
Partners & Clients
Get in Touch With Our Team.
Send your footprint, your flow and what's moving next year — a drawing helps, a photo of the floor works too.
What Goes Into the Layout
An efficient facility layout weighs all of it at once — that’s the job.
Cube utilization
Movement reports and flow data
Projected material flow
Machine layout and placement
Shipping and receiving locations
Building columns and obstructions
Aisle and traffic planning
Storage density and slotting
Conveyor and transfer routing
Mezzanines and vertical space
Expansion allowance
Phased implementation planning
Where product actually travels is the first drawing.
Material Flow Decides the Layout — Not the Other Way Around.
Plenty of layouts are storage plans with aisles. A working layout starts from how material moves — receiving to storage, storage to the line, the line to the truck — and puts the machines, rack and docks where the flow says they belong. Project-specific requirements and procedures get understood first; the drawing comes second.
What a Layout Study Answers
The questions worth settling before anyone signs a lease or pours a slab.
More building, or better flow?
Often the square footage is there — it’s just arranged around history instead of flow. The study shows what the current walls can still do.
Where do the docks belong?
Shipping and receiving locations set the direction of every move inside. Getting them right simplifies everything downstream.
What happens at twice the volume?
A layout that only works at today’s rate is a short-term plan. Growth gets drawn in as expansion allowance, not discovered later.
What does each option cost?
There are usually several workable answers at different price and performance points. The more options you can compare, the better the decision.
Cube utilization is the cheapest space you’ll ever find.
The Best Layout Uses the Air, Not Just the Floor.
When the floor is full, the answer is often overhead — mezzanines, vertical transfers, and storage that uses the building’s height. Cube utilization is a standard input to every Conveyability layout, because the most expensive fix is the addition you didn’t need.
